T0022 - Small 0.80ft³

The Coldtainer T0022 series is a versatile high-performing top-loading unit that is perfect for pharmaceutical or medical transport, or for operations that need to fit multi-temperature options in the same vehicle. With its sleek and rugged design, iso-thermal triple insulated construction, and precise temperature control, the T0022 can store and deliver whatever product you need. With the T0022 unit’s ability to easily load and unload, swap between vehicles, and multi-temp. capability, delivery and logistic operations can rest assured that the “last-mile” will be the safest.

Available versions

  • Coldtainer Freezer with Heat
  • Coldtainer Freezer
  • FDH from +104F down to -11F+104F to -11F
  • FDN down to -11F to -11F

T0022 Accessories

Dc cord 5mt 540011/01

540011/01

Red yellow AP connectors interface 540014/00

540014/00

Ac/Dc power supply 150W 560019/00

560019/00

Fixing kit 850022/00

850022/00

Internal fan kit 850048/00

850048/00

Protection cover 850075/00

850075/00

Coldtainer Bluetooth App Application iPhone Android Temperature Monitor Control Refrigerated Frozen Delivery Storage Transport Vehicle Tracking Temp Container

HACCP Bluetooth Interface 510012/00

510012/00

Advantages of the Coldtainer T0022

TYPE

Top loading refrigerated container.

TEMPERATURE RANGE

-11°F to +104°F (freeze-protection available on select models).

INTERNAL CAPACITY

0.8 cubic feet (6 gallons).

INSULATION

2.75 inches of specialized industrial polyurethane offering perfect thermal insulation.

PRECISE TEMPERATURE CONTROL

Coldtainer's advanced technology and manufacturing process ensures that each unit will consistently hold its internal temperature accurately down to the single degree.

COLD CHAIN INTEGRITY

From point-of-origin to delivery endpoint, the T0082 maintains an accurate temperature setpoint. And with the ability to easily switch the container between vehicles and power the unit from any outlet, you never have to take your products out until you're ready.

MANUFACTURING PROCESS

Each Coldtainer unit is created with our specialized rotational-molding manufacturing process, creating a single piece container without internal junctions or sharp corners for easy cleaning. With its sturdy construction and advanced engineering, your T0082 will serve you well for years to come.

Overall T0022 dimensions

You can download the pdf of internal and external dimensions for each T0022 model here. Please note that all technical drawing measurements are in centimeters.

Product Dimensions T0022_FDH Product Dimensions T0022_FDN
